Baum 714XLT Ultrafold Air Feed Paper Folder
Baum 714XLT Ultrafold Air Feed Paper Folder
How to Purchase This Item:
How to Purchase This Item:
- Web: Sales Contact Form
- Call: 1-800-343-4231
- Email: sales@midstatelitho.com
- Text: (810) 238-7370
The Baumfolder Ultrafold 714XLT air feed tabletop folder combines all the rugged reliability of the larger model Baumfolders in a compact, convenient size. The 714XLT is ready to go to work for you anytime and anyplace you need it. It can easily handle coated stocks as well as high-speed copier and laser-printed stocks. It can easily handle coated stocks as well as high-speed copier and laser-printed stocks.
- Non-marking, continuous feeding with bottom feed system
- Toner resistant and static dissipative folding rollers
- Sealed ball bearings, no lubrication needed
- Removable cartridge design slitter shafts
- Gear-driven folding rollers, no slippage during folding
- Automatic roller tensioning
- Quiet pump that handles both the vacuum and the air blow
- UL approved
- Rack and pinion gear side guides on feed table to maintain squareness
- Second pass folding capability with exclusive air control system
- Total counter
- Loads and unloads from the same end of the machine
| Type folder | Air feed, bottom feed |
| Maxixmum sheet size parallel | 14" x 20" (35.5 x 50.8 cm) |
| Maximum sheet size right angle | 13.5" x 14" (34.2 x 35.5 cm) |
| Minimum sheet size | 3" x 5" (7.6 x 12.7 cm) |
| Maximum size fold - #1 or #2 plate | 13.5" (34.3 cm) |
| Minimum size fold | 2.25" (5.7 cm) |
| Maximum paper weight | 65 lb cover |
| Feeder pile height | 2" (5.1 cm) |
| Fold roll diameter | 1.5" (3.8 cm) |
| Fold roll material | Either Polyurethane or combination of Polyurethane/Steel |
| Parallel fold roll speed | Infinitely variable between 0"/min and 7200"/min (0 to 18,288 cm/min or 182 m/min) |
| Righ-Angle fold roll speed | 5000"/min |
| Operating voltage | 110 VAC - 60 Hz |
| Power consumption | 1500 watts |
| Amperage (pump) | 13.6 amp |
- Laser-printed & high-speed copier stock capability (up to 14" x 20")
- Heavy-duty construction with floor-model folder features
- Built-in totalizing counter
- Multiple air adjustments for feeding consistency on varying applications
