Perfecta 92 TS 36" High Speed Paper Cutter

Perfecta 92 TS 36" High Speed Paper Cutter

This Product is Discontinued

Browse our collections to find a modern replacement or simply reach out to our sales team.

Perfecta 92 TS High-Speed Paper Cutter Product Details:

The Perfecta 92, even though economically priced, is designed with durability and productivity in mind. Capable of operating in a 24/7 environment, all safety features and accuracy is the same as the larger machines. Productivity features like 50 strokes per minute knife, 12 inches per second backgauge, slotless bed and high speed knife change gives Perfecta the advantage over the competition.

  • Powerful gear drive for the knife
  • Digital servo drive positioning system for the backgauge
  • Hydraulic clamp
  • Stainless steel plated and slot-less cutting table
  • Cutting table and side tables with air bed
  • TS computer with 18.5" high resolution color touch screen
  • CIP3 / CIP4 enabled LED table lgith and cut line indicator
  • Built-in knife hoist with setting gauges and knife guard
  • Self monitoring safety light barrier
  • Two-handed cut control
  • Complete rear table guarding
  • Overload protection device

Available Options:

  • Enlarged air side tables
  • Carbide tipped blades
  • Lift kit for taller working height
  • Automatic Waste Removal System AWR
  • Smart clamp (Limited clamping stroke)
  • Low pressure device (for corrugated and pressure sensitive material)
  • Barcode scanner
  • S2C package (Straight to Cut), with barcode scanner and CIP3/4 network connectivity
  • Swivel backgauge
  • Built-in knife cleaning device for glued products
  • Variable knife speed

     Technical Specifications:

    Cutting Table Width 36 "
    Cutting Table Height 34.25"
    Smallest Cut 0.7"
    Smallest Cut with False Clamp 2.2"
    Maximum Clamp Opening 4.7"
    Useful Rear Table Length 36"
    Knife Cycle Rate 50 Cuts / Min
    Maximum Backgauge Speed 12" / Sec
    Main Drive Power 4 hp
    Weight 4,410 lbs
