Konica Minolta AccurioPress C4070 Digital Press

Konica Minolta AccurioPress C4070 Digital Press

How to Purchase This Item:

Konica Minolta AccurioPress C4070 Digital Press

The Konica Minolta AccurioPress C4070 Digital Press is a mid-volume all-in-one digital press featuring advanced automation and ease of use opening opportunities for your business to expand. By streamlining workflow and delivering printed output that exceeds customer expectations, the C4070 will take on many new print applications other digital presses cannot, saving you time and increasing profitability. In addition, these machines have a very low cost of operation.

For example, At 70 ppm, the press offers 2-sided printing sheets up to 34” long, professional finishing, excellent image quality, and real-time automated quality adjustments. This product provides a unique level of automation with the inline TU-510 Trimmer Unit. Trimming that is so simple an inexperienced operator can run even the most complex projects. Therefore the productivity of this machine can stay at a peak level with new operators.

  • CMYK Toner Based Device
  • Variety of Finishing Options Available
  • EFI, Creo, and Konica Minolta Controllers

Konica Minolta AccurioPress C4070 Digital Press Specifications

Name

AccurioPress C4080/AccurioPress C4070/AccurioPrint C4065

Type

Console type

Color compatibility

Full color

Print method

4 drum tandem laser electrostatic copying system

Photoconductor

OPC

Development method

Dry 2-component

Transfer type

Belt transfer/roller transfer

Fusing method

Belt fixed

Gradation/Expression color

256 gradation (8-bit) / 16.7 million color

Paper weight (machine tray)

Plain paper, fine paper, color specific paper, textured paper: 62 g/m2 to 256 g/m2* / 16 lb Bond to 68 lb Bond*

Coated-G,Coated-M: 81 g/m2 to 256 g/m2* / 22 lb Bond to 68 lb Bond*

*: 217 g/m2 to 256 g/m2 / 58 lb Bond to 68 lb Bond settings are only for A4 vor 8.5 e 11 v or higher paper.

Paper size (machine tray)

Tray 1 (Upper tray)

Standard: A3 w, B4 w, SRA4 w/v*, A4 w/v, B5 w/v, A5 w, 11 e 17 w, 9 e 11 v, 8.5 e 14 w, 8.5 e 11 w/v, 5.5 e 8.5 w, 8 e 13 w, 8K w, 16K w/v

Custom: Widthwise 139.7 mm to 330.2 mm, lengthwise 182 mm to 431.8 mm / Widthwise 5.5" to 13", lengthwise 7.17" to 17"

Tab paper: A4T v, 8.5 e 11T v

Tray 2 (Lower tray)

Standard: SRA3 w, A3 w, B4 w, SRA4 w/v*, A4 w/v, B5 w/v, A5 w, 13 e 19 w, 12 e 18 w, 11 e 17 w, 9 e 11 v, 8.5 e 14 w, 8.5 e 11 w/v, 5.5 e 8.5 w, 8 e 13 w, 8K w, 16K w/v

Custom: Widthwise 139.7 mm to 330.2 mm, lengthwise 182 mm to 487.7 mm / Widthwise 5.5" to 13", lengthwise 7.17" to 19.2"

*: Metric area only

Tab paper: A4T v, 8.5 e 11T v

Series B paper is set to JIS or ISO standard size by default. This setting differs depending on the shipping region. For JIS/ISO switching, contact your service representative.

Detectable fixed sizes can be changed. Furthermore, use of K size can be selected on the [Utility] screen..

Tray capacity (machine tray)

Tray 1 (upper tray) 500 sheets (80 g/m2 / 21 lb Bond)

Tray 2 (lower tray) 1,000 sheets (80 g/m2 / 21 lb Bond)

Feedable paper size

Straight output/Duplex

Standard: SRA3 w, A3 w, B4 w, SRA4 w/v, A4 w/v, B5 w/v, A5 w/v, B6 w, A6 w, 13 e 19 w, 12 e 18 w, 11 e 17 w, 9 e 11 v, 8.5 e 14 w, 8.5 e 11 w/v, 5.5 e 8.5 w, 8.5 e 13 w, 8.25 e 13 w, 8.12 e 13.25 w , 8 e 13 w, 8K w, 16K w/v

Custom:

Straight output
Widthwise 100 mm to 330.2 mm, lengthwise 148 mm to 1,300 mm / Widthwise 3.94" to 13", lengthwise 5.83" to 51.18"

Duplex
Widthwise 100 mm to 330.2 mm, lengthwise 148 mm to 864 mm / Widthwise 3.94" to 13", lengthwise 5.83" to 34.02"

Tab paper (single side only): A4T v, 8.5 e 11T v

Back on Top Output

Standard: SRA3 w, A3 w , B4 w, SRA4 w/v, A4 w/v, B5 w/v, A5 w, 13 e 19 w, 12 e 18 w, 11 e 17 w, 9 e 11 v, 8.5 e 14 w, 8.5 e 11 w/v, 5.5 e 8.5 w, 8.5 e 13 w, 8.25 e 13 w, 8.12 e 13.25 w , 8 e 13 w, 8K w, 16K w/v

Custom: Widthwise 139.7 mm to 330.2 mm, lengthwise 182 mm to 487.7 mm / Widthwise 5.5" to 13", lengthwise 7.17" to 19.2"

Tab paper: A4T v, 8.5 e 11T v

Allowed weight for machine feed

Back on Top Output, Duplex: 62 g/m2 to 360 g/m2* / 16 lb Bond to 95 lb Bond*

*: 301 g/m2 to 360 g/m2 / 82 lb Bond to 95 lb Bond is available only for A3 w to SRA3 w.

Warm-up time

6 minutes 30 seconds or less (23°C, 50%RH, rated voltage when electric current is running through)

First copy time

AccurioPress C4080: Monochrome 4.0 seconds or less, Color 6.1 seconds or less (A4 v, 8.5 e 11 v)

AccurioPress C4070/AccurioPrint C4065: Monochrome 4.0 seconds or less, Color 6.5 seconds or less (A4v, 8.5 e 11 v)

Power

AccurioPress C4080 / AccurioPress C4070:

Inch Area: AC 208 V to 240 V / 24 A, 60 Hz

Australia and New Zealand: AC 220 V to 240 V / 20 A, 50/60 Hz

AccurioPrint C4065:

Inch Area: AC 208 V to 240 V / 16 A, 60 Hz

Maximum power consumption

AccurioPress C4080 / AccurioPress C4070:

Inch Area: 5,760 W

AccurioPrint C4065:

Metric area: 3,840 W

Inch Area: 3,840 W

*Device system values besides the options that use dedicated power cords

Weight

312 kg / 687.84 lb (machine only)

Dimensions

800 mm (W) *1 e 903 mm (D) *2 e 1,076 mm (H) *3 / 31.5" (W) *1 e 35.55" (D) *2 e 42.36" (H) *3 (Machine + Original Cover OC-511)

*1: Excluding operating parts, output tray and working table.

*2: Including rear duct.

*3: Height of top of Original Cover OC-511 without the operational parts.

Machine occupied dimensions

5,192 mm (W) *1 e 1,734 mm (D)*2 / 204.41" (W)*1 e 68.27" (D)*2

(Machine + Reverse Automatic Document Feeder DF-713 + Paper Feed Unit PF-707m + Relay Unit RU-518m + Relay Unit RU-510 + FoldingUnit FD-503 + SaddleStitcher SD-506 + Finisher FS-532)

*1: When the Finisher FS-532 main tray is pulled out

*2: Ensure space of 631 mm / 24.84" in front of the machine (when Fusing Conveyance Unit is pulled out), and 200 mm / 7.87" from the back duct on the back side.

Usage environment

10°C to 30°C

10%RH to 80%RH
