Streamfeeder P-Series Friction Feeders
Increase efficiency with the Streamfeeder P-1250 On-Demand Feeders. High-speed feeding for various media, perfect for packaging and mailing solutions.
Request a Quote
Tell us what you need—we’ll follow up quickly with pricing and options.
Ask a Question
Specs, compatibility, install, supplies—ask anything. A finishing specialist will reply quickly.
Downloads
Details & specifications
The P Series Friction Feeders by Streamfeeder are versatile and efficient solutions designed to seamlessly integrate with various host and control systems, including cartoners, case erectors, wrappers, and warehouse management systems (WMS). Capable of handling a wide variety of flat and multi-thickness products, these feeders operate on-demand, one at a time, in batched sets, or in continuous feed mode.
Key Features:
- High-Speed Operation: Belt speeds of up to 7,000 inches per minute (178 meters per minute) ensure efficient production.
- Versatile Media Handling: Handles a wide range of product sizes and thicknesses, perfect for diverse applications.
- User-Friendly Interface: Features an Allen-Bradley touch screen for intuitive operation and control.
- Durable Construction: Built with stainless steel construction and long-lasting gum rubber feed belts with vacuum assist.
- Batch Counting Capabilities: Precision batch counting from 1 to 9,999 for optimal production management.
- Safety Features: Includes miss-detect, photo-sensor trigger, and timeout stop for secure and reliable operation.
Specifications:
Access P-600 Product Sheet Heere
P-1250 Access Product Sheet Here
P-1800 Access Product Sheet Here
| Specification | P-600 | P-1250 | P-1800 |
|---|---|---|---|
| Batch Size | 1-9,999 | 1-9,999 | 1-9,999 |
| Belt Speed | 7,000 in/min (178 m/min) | 7,000 in/min (178 m/min) | 7,000 in/min (178 m/min) |
| Min/Max Product Thickness | .003” to 1.0” (.076 to 25.4 mm) | .003” to 1.0” (.076 to 25.4 mm) | .003” to 1.0” (.076 to 25.4 mm) |
| Maximum Product Size | 6” W x 9” L (152 x 229 mm) | 12” W x 14” L (305 x 357 mm) | 18” W x 14” L (457 x 357 mm) |
| Minimum Product Size | 2” W x 2.5” L (51 x 64 mm) | 2” W x 2.5” L (51 x 64 mm) | 8” W x 2.5” L (203 x 64 mm) |
| Weight | Feeder: 45 lbs (20.4 kg); Control Box: 36 lbs (16.3 kg) | Feeder: 50 lbs (23 kg); Control Box: 36 lbs (16.3 kg) | Feeder: 50 lbs (23 kg); Control Box: 36 lbs (16.3 kg) |
| Utilities | 115/230vac, 50/60 Hz, 12/6A | 115/230vac, 50/60 Hz, 12/6A | 115/230vac, 50/60 Hz, 12/6A |
| Warranty | One year limited | One year limited | One year limited |
Â
Optional Features:
- Adjustable discharge
- Double sheet detect
- Low stack detect
- Powered rotating gate
- Small product configuration
- Speed matching
- Tower lamp
- Vacuum transport
- Vertical discharge
Applications:
- Batch Counting, Cartoners, Case Packers, Collators, Envelope Inserters, Flow Wrappers, Order Fulfillment, Poly Baggers, Shrink Wrappers, and more!
Benefits:
- Efficiency: High-speed feeding reduces downtime and boosts productivity.
- Versatility: Handles a wide range of applications and product configurations.
- Ease of Use: Simple controls and advanced features make operation intuitive.
- Durability: Built to withstand demanding production environments.
